LCD KVM over IP Console with 16 port VGA KVM-17

LCD KVM over IP Console with 16 port VGA KVM-17

(1 đánh giá)


The XL1716i KVM over IP console is a control unit that allows you to control one or many computers locally at the server site or remotely via the Internet using a standard browser. An extra console port is provided on the rear panel to manage the LCD KVM switch from an external console. The XL1716i integrates a 16 port VGA KVM switch together with the LCD panel allowing access and control with up to 16 computers from a single console (keyboard, mouse, and monitor). By cascading additional 31 swi

18,899,000 đ

18,899,000 đ

Hardware feature

  •  One 16 port VGA KVM switch is integrated in 1U height console, it controls multiple computers via a set of device(LCD monitor, keyboard, mouse)
  •  Standard VGA connector-Connect to a server or computer via a standard VGA connector

High Performance Touchpad

  •  Touchpad with trackball- Eliminates the need for a separate, external mouse


  •  Multi-language support--English, Russian, German, French, Korean, Swedish and Italian, etc.
  •  Full size 99 keys keyboard with integrated number pad

Management Way

  •  Supports 1 remote user access to the KVM via network browser with TCP/IP communication protocol
  •  Convenient computer switching via front panel LEDs, OSD menu and mouse
  •  Remote access to the KVM(Keyboard, video and mouse) through modem
  •  Support any operating system even in BIOS level, during start up or in blue screen
  •  Supports JAVA browser remote control
  •  Auto scan feature for monitoring user-selected computers
  •  Broadcast mode--operations simultaneously performed on all selected computers

High Resolution

  •  17” TFT LED monitor with highlight, high definition and high resolution
  •  Local video resolution:1280 x 1024 @75H,remote video resolution:1600 x 1200 @ 60Hz
  •  Automatically adjust video resolution when switching between servers

Cascade Feature

  •  Directly access and control up to 16 servers with single XL1716i
  •  By cascading to another 31 switches, as many as 512 servers can be controlled


  •  Two level password security--only authorized users view and control computers; up to four users and an administrator with a separate profile for each
  •  All transmitting data are encrypted with SSL 256 bits
  •  SSL certificate management

Wide Compatibility

  •  Multi-platform Support-Compatible with Windows, Sun, Unix and Linux
  •  Supports server form Lenovo, HUA WEI, HP, IBM, Cisco and Dell, etc.
